Tom NMH has switched back to his old callsign, WA5MAZ from the mid 1960s. At the Thurs 03.26 meeting he brought in two (2) Motorola handy t – well, back then they were more like lunch boxes, the one from 1958 mostly transistors (except driver and final tubes – little ones, 1W out), and the other from 1948, one year after Shockley and the other two guys invented the point contact transistor, It was all tubes, a bunch of them, like 19 little ones, mostly mounted in replaceable/fixable modules like the one shown above, part of the crystal multiplier chain that makes 146 Mc from a crystal in the 12 Mc area. Tom has used the old ‘Lunch Box’ Motorolas on the 146.91 repeater. It’s a little trick to do that since Int’l Crystal Co. doesn’t make crystals any more, and that’s another story about Tom, using a freq synthesizer chip to program not only a 12 Mc crystal, but also a PL tone. We asked him, Why don’t you just buy a Baofeng, but I guess he likes to display his talents

Kenny KJ5EKW brought in a heavy 14 VAC transformer and asked about making a power supply. The linear Astrons start with a little more voltage that comes out around 21VDC. One idea was to use the 7812 type regulator chip which can regulate with as little as 2 Volts difference. (14VAC times 1.414 yields 19.7; less 1.4 for loss in hte bridge rectifier; now 17.3; less maybe a Volt of ripple with a large (80,000 uF) filter capacitor; down to 16.3 that could be regulated to the 13.8 – 14.0 DC range.
